Apex Horizontal And Vertical Rotary Milling Table 8 Inch 200mm

Product Description

• The table and base are manufactured from close-grain shock-resisting cast iron, which is fully stress relieved.
• The worm and centre table bush are made of high-quality steel.
• On the hand wheel scale, direct reading to 2 minutes for sizes 6", 8", and 10".
• On the hand wheel scale, direct reading to 1 minute for sizes 12", 15", 18", and 20".
• Maximum error of 4 minutes of circular division using hand wheels.
• To within 0.01 mm (100 mm), the table is flat.
• The working surface rotates in its own plane to within 0.030mm and 0.01 mm/100 mm of the horizontal and vertical supporting surfaces.
• The centre bush bore is true to the table axis within 0.03 mm.
• The maximum parallelism error through 360 of rotation of the table is .025 mm.
• The base is provided with two bolt slots in 715E: both horizontal slots in and vertical mounting on the machine table.
