Vertex K Type Milling Vise Without Base 112mm Vk-6-1

Product Description

Features:

Brand: Vertex

SKU: VK-6-1

Type: K-Type Milling Vise

Jaw opening: 112 mm

Jaw Width: 154 mm

Base: Without Base

Description:

• Vertex make VK model K Type milling machine vise are the traditional machine vises with lead screw mechanical clamping. system and high rigid single piece fixed jaw casting and delivering a clamping force of 900 kgf to 1400 kgf.
• VK model Vises are designed with detachable Right Angle Handle and swivel base along with the Vise.
• VK model Vises have a design feature of more contact area on the movable jaw and more surface contact in clamping area due to external lead screw mechanism.
• VK model has accuracy guarantee of 0.01/100mm parallel and 0.02/50mm perpendicularly.
• VK model has bending proof.
• Application: VK model Vises are selected according to the application on 3 major criteria's.
• Jaw opening of Vise (As per work piece maximum sizes).
• Jaw width of Vise (As per work piece size).
• Machine spindle power (Recommended As per the below chart).
• Vise For 1 HP spindle power VK-4,VK-5.
• Vise For 2 HP spindle power VK-5,VK-6.
• Vise For 3 HP spindle power VK-6.
• Vise For 5 HP spindle power VK-8.
• Vise jaw accuracy within 0.02mm.
• Excellent precision and a High quality finished Vise.
• Jaw plates were made of hardened and grounded tool steel.
• It is used for milling, grinding and drilling Vise requirements.
• Traditional Vises built for heavy duty machine and retained accuracy.
